Polygon Tent
The Polygon Tent is constructed with a series of polygonal aluminum alloy beams, eliminating the need for interior support poles. This innovative design enhances structural strength and durability while providing an unobstructed clear span roof, thus creating a spacious indoor environment. The Polygon Tent offers ease of installation for both permanent and temporary use, with the flexibility to relocate or expand according to your specific needs.
This tent is highly favored and widely utilized in various applications, including concerts, sports arenas, stadiums, courts, exhibitions, warehousing solutions, large-scale events, parties, trade shows, and more.
Our range of Polygon Tents encompasses span widths ranging from 10 meters to 60 meters, catering to a wide spectrum of spatial requirements.
Gallery
Models & Sizes (Span width from 3M to 50M)
| Span Width | Eave Height | Bay Distance | Main profile | Wind Load |
|---|---|---|---|---|
| 10m | 4m/6m | 5m | 220x100x4mm/ 203x112x4mm | 100km/h |
| 12m | 4m/6m | 5m | 220x100x4mm/ 203x112x4mm | 100km/h |
| 15m | 4m/6m | 5m | 220x100x4mm/ 203x112x4mm | 100km/h |
| 20m | 4m/6m | 5m | 220x100x4mm/ 203x112x4mm | 100km/h |
| 25m | 4m/6m | 5m | 250x120x4mm | 100km/h |
| 30m | 4m/6m | 5m | 300x120x6mm | 100km/h |
| 40m | 4m/6m | 5m | 300x120x6mm | 100km/h |
| 50m | 4m/6m | 5m | 350x120x6mm | 100km/h |
| 60m | 4m/6m | 5m | 400x120x6mm | 100km/h |
Features, Accessories and Cutom Design
| Frame material | Hard pressed aluminum alloy T6061/T6 |
|---|---|
| Fabric cover | double PVC-coated polyester textile; 100% waterproof;UV resistant, tear-resistant, self-cleaning ability, etc. |
| Roof cover | 850g/sqm white PVC Fabric |
| Sidewall cover | 650g/sqm white PVC Fabric |
| Fabric color option | White, yellow, transparent and customized |
| Connector | Strong hot-dip galvanized steel. |
| Allowed temperature condition | -30 degree Celsius +70 degree Celsius |
| Wind load | 80-100km/h |
| Snow load | 75kg/sqm (snow can’t stay if use big degree roof pitch design) |
| Other features | Easy to assemble and disassemble No pole inside, 100% available interior space |
- PVC window sidewalls
- Anchoring
- Rain Gutter
- Lining and curtain
- Glass door units
- Hard walling system
- Glass walling system
- Transparent PVC cover and sidewall
- Flooring system
- Weight plate
More accessories are available, please feel free to contact us if you need more information.
